B MORE DISCUSSIONS

B.1 Necessity of Proxy-guided 3D Generation

For personalized generation demands, we think only using text / images is insufficient and also unintuitive for expressing 3D structures of objects and their spatial relationships. Hence, granting

system 3D-aware controllability with 3D proxy is necessary for 3D generation. As for the acquisition of 3D proxies, we believe this is not an obstacle for target users, as it can be assembled easily using kids’ software like Tinkercad, taken from 3D modeling games from SteamVR, or using LLM+procedural modeling instructions. Similarly, ControlNet uses control images from raw sketches to delicate line art, which also requires basic painting skills.

B.2 More Limitations

First, the resolution of 3D-aware control is bounded by the size of the proxy feature volume, which cannot fully leverage control from complex high-poly models. For example, we cannot generate a large-scale urban scene with satisfactory building details. Second, our method requires manual tuning control strength to balance between over-constrained and under-constrained, which is also similar to ControlNet [Zhang et al. 2023] as the control strength mainly depends on the creators’ aesthetic choices.
